Precision Optical Patterns for the Medical Industry For the Endoscopy industry, Opto-Line provides the highest quality apertures for medical endoscopes and laparoscopes. In the area of Optometry & Opthamology, we craft reticles, ellipses, metrology targets, and many other custom patterns which serve dozens of Universities, Visual Science Centers, Eye Institutes, Ophthalmology Schools, etc. With more […]

Our Resolution Test Targets Meet all MIL Standards Still widely used as an accepted method to test the resolution of optical imaging systems including microscopes, cameras and image scanners, resolution test targets are a specialty of Opto-Line. For more information about how we can help meet your test target needs, we invite you to call […]

Opto-Line patterns on a myriad of substrates including all glass material and other IR materials including geranium, silicon, zinc sulfide, quartz, and sapphire. The largest substrate size that Opto-Line can pattern is approximately 12.5” diagonal. The smallest part that can be manufactured is about 1mm x 1mm.

Opto-Line International has been creating custom precision patterns on optics since 1967 We are not your standard, stock reticle company. Instead, Opto-Line manufactures your unique, custom patterns on optical substrates per your requirements. From reticles and apertures to multi-density resolution masks and almost any pattern imaginable, our photolithography and thin film coatings practices are optimized […]

For many years, Opto-Line has supplied high-end EMI grids on IR substrates, reticles, and custom patterned optics for defense systems including scopes, laser range finders, target designator systems and other critical applications.

Opto-Line’s team is highly experienced in crafting reticles, ellipses, metrology targets, and many other custom patterns for the Optometry & Opthamology industries. “We are realizing things that Opto-Line can do for us that we never even thought within our reach.” Alfredo Dubra Associate Professor of Ophthalmology, Stanford University

Specializing in custom precision optical patterns for all areas of research and development, Opto-Line helps clients reach their R&D goals. Our custom patterns are often vital components in the R&D phase of a product. We have a long history of partnering with companies across an array of industries to help them achieve their product goals. […]

Our highly skilled team has over 160 combined years of service at Opto-Line International. As an industry leader in the manufacturing of precision reticles, we are dedicated to the highest quality custom optical patterns and coatings. Our 9800 sq ft facility includes a Class 100 clean room, multiple high-vacuum evaporation chambers, and modern equipment allowing […]

Combined with our specialized photolithography, Opto-Line utilizes thin film coatings to make your custom patterns. Some examples of our custom patterning capabilities include reticles, resolution test targets, EMI grids, apertures, linear scales, and neutral density step tablets. Opto-Line can typically tackle any custom pattern imaginable.

From 1951 USAF resolution test charts to almost any custom test targets imaginable, Opto-Line will produce the finest optical patterns to meet your needs.
