Custom Patterns

We are not your standard, stock reticle company. Opto-Line is synonymous with customization. We are proud to deliver some of the most difficult custom optical pattern designs that that require a very high degree of precision, experience and ingenuity. Within our limitations of about 1μm, we can produce any pattern you may need with the […]

We have refined our processes over the years to provide patterns on curved substrates (lenses). Concave and Convex substrate patterning requires special, proprietary techniques combined with meticulous care and experience.

Opto-Line offers custom patterning capabilities include reticles, resolution test targets, EMI grids, apertures, linear scales, and neutral density step tablets. We  can typically tackle any custom pattern imaginable. Combined with our specialized photolithography, Opto-Line utilizes thin film coatings to make your custom patterns. Our high-vacuum evaporation chambers provide us with the ability to precisely deposit […]

Opto-Line’s Metrology services provide precision components for calibration, measurements and alignments. We invite you to learn more about our Metrology Services – Click below to read more.

Opto-Line provides the highest quality apertures for medical endoscopes. Typically utilizing our proprietary low-reflecting black chrome, our apertures have become the benchmark for endoscope manufacturers. To learn more about our expertise in the areas of Endoscopy and Optometry/Ophthalmology, reach out to us today.

Our beam splitter patterns are ideal for numerous optical systems. A beam splitter is a device for dividing a beam of light or other electromagnetic radiation into two or more separate beams. Offering a distinct advantage over standard dielectric beamsplitters, Polka-Dot Beamsplitters have a constant reflection/transmission ratio over a large spectral range and are ideal […]

Opto-Line uses the following methods for our customer’s custom Multi-Density Resolution Masks: Half Tone: By using very small dots and changing the amount of the dots, we can create varying densities that typically fulfill our customers’ needs. Continuous: Discrete, individual depositions of Inconel are used to create each density. In this case, Opto-Line requires separate […]

We are not your standard, stock reticle company. Instead, Opto-Line manufactures your unique, custom patterns on optical substrates per your requirements. Within our limitations of about 1μm, we can produce any pattern you may need with the precision and quality you should expect. From reticles and apertures to multi-density resolution masks and almost any pattern […]

Opto-Line has provided various custom patterns typically utilizing our low-reflecting black chrome. For Aerospace applications, our precision pattern and coatings are often found in systems created by the most well-known companies. Many of our aerospace reticles are used in sun angle sensor systems on satellites. Our durable black chrome has a Rave <5% over the […]
